An excellent solution & safe environment to overcome architectural barriers.
Focused in making our solution seriously affordable.
Accesibility for all with a reliable & performant hydraulic lift equipment.
HOME LIFT
Lista de servicios
-
General SpecsElemento de lista 1
Max load Q = 500 Kg.
Max Speed 0,15 m/s.
Min Pit 350 standard
(For pits <350 please ask your sales representative).
Min Headroom 2600 mm with automatic sliding door.
Min Headroom 2300 mm without car door + safety edge photocells.
-
Hydraulic equipmentElemento de lista 2
Fluitronic pack HL from GMV
Piston: 1 or 2 stage piston, indirect traction.
Max. (stops): 5 stops - 12m travel
Diameter (mm): 60 - 70 - 80 -90
Thickness (mm): 5 - 7,5 - 12
Options:
NGV electronic valve kit for more performance optimization.
Full cabinet for controller+pump
Mineral Fluid HV46
-
DoorsElemento de lista 3
Choose between Wittur Augusta , Hydra automatic doors or without any car door + manual semi door.
-
Electrical SpecsElemento de lista 4
Edel K3 for hydraulic home lifts, available in several languages and for machine room or MRL (with full cabinet)
